37.75" × 75.5" double-sided Crossfire Series 6 outdoor LED display. Its modular LST6 cabinet platform is engineered for bright, all-weather commercial messaging and front-or-rear service.
Display specifications
Screen size
37.75" × 75.5" / 2-sided
Screen resolution
144 × 288 pixels per display face
Model
LST6
Pixel pitch
6.67mm
LED package
SMD2727
Pixel matrix per cabinet
144 × 144
Pixel density
22,500 pixels/m²
Cabinet size
960 × 960 × 91 mm
Module size
480 × 320 mm
Brightness
7,500 nits
Refresh rate
3840 Hz
Grayscale
14-bit / 16,384 levels
Ingress protection
IP65 front / IP65 rear
Service access
Front and rear
Maximum power
740 W/m² ±15%
Typical power
236 W/m² ±15%
Rated lifetime
100,000 hours
Standard features
Die-cast cabinet with aluminum module shell
Wi‑Fi-ready control and advanced receiving card
Playlist and content scheduling
Free cloud-based software
5-year warranty; terms apply
After-sale support
Pricing and project scope: The current Shopify price is retained because the matched Crossfire technical sheet does not provide a reliable size-specific price.
